Discontinued Product

This product has been discontinued by the manufacturer. Contact us for alternatives.

AXIS P1290-E from AXIS COMMUNICATIONS - box IP camera - product image
Click to enlarge
Request a Quote
Axis CPP Solution Gold Partner
5-year warranty5-year
warranty

AXIS P1290-E Thermal Network Camera

Model: AXIS P1290-E

Understand code
Request a Quote

Professional AXIS P1290-E Thermal Network Camera solution from Axis Communications

  • zipstream
  • edge storage
  • analytics
⚠️Discontinued Product⚠️On requestACAP
Download Datasheet

Overview

  • zipstream
  • edge storage
  • analytics
The AXIS P1290-E is a fixed thermal sensor unit from Axis Communications, designed for professional security and surveillance in challenging conditions. It features an uncooled microbolometer sensor that detects heat signatures with a 35.4° field of view, supporting H.264 compression and built-in edge video analytics for reliable performance. This discreet unit integrates seamlessly with leading VMS platforms via ONVIF and includes a 5-year manufacturer warranty.

Technical Specifications

ACAP Supported
Image Sensor
Uncooled microbolometer
Thermal Sensitivity (NETD)
<100 mK
Thermal Sensor Resolution
208x156
Maximum Video Resolution
640x480
Frame Rate (fps)
8.3
Thermal Palettes
Yes
Focal Length
4 mm
Horizontal Field of View
35.4 °
Vertical Field of View
28 °
Axis Zipstream
Yes
H.264
Baseline, High, Main
Video Motion Detection
Yes
PoE Class
2
Signed OS
Yes
Local Storage (Memory Card)
Yes
Operating Temperature
-30 to 55 °C
Ready for external use
Yes
IP Rating
IP66, IP67

Available APIs

VAPIXParameterVideoEvents

Security

HTTPSPassword protection

Networking

IPv4IPv6HTTPS

Video Analytics

Motion DetectionTampering DetectionAudio Detection

Downloads

Datasheet

Datasheet•PDF
ViewDownload

Installation Guide

Other•PDF
ViewDownload

Installation Guide

Other•PDF
ViewDownload

Overview

Other•PDF
ViewDownload

Camera

Other•PDF
ViewDownload

Brochure

Other•PDF
ViewDownload

Thermal Technology Glossary

Other•PDF
ViewDownload

Comparison

Other•PDF
ViewDownload

Comparison

Other•PDF
ViewDownload

Declaration of Conformity

Other•PDF
ViewDownload

MTBF Declaration

Other•PDF
ViewDownload

Declaration of Conformity

Other•PDF
ViewDownload

Discontinuation Notice

Other•PDF
ViewDownload

Support

Warranty

Axis standard warranty: 5 years against manufacturing defects.

Contact Aeon

Need help with this product?

Talk to a specialist →

Frequently Asked Questions

What is the AXIS P1290-E and what is it used for?+

The AXIS P1290-E is a fixed camera from Axis Communications. The AXIS P1290-E is a fixed thermal sensor unit from Axis Communications, designed for professional security and surveillance in challenging conditions. It features an uncooled microbolometer sensor that detects heat signatures with a 35.4° field of view, supporting H.264 compression and built-in edge video analytics for reliable performance. Available in the United States through Aeon Security, an authorized Axis partner.

What is the resolution and image quality of the AXIS P1290-E?+

The AXIS P1290-E captures images at a resolution of 208x156 using a Uncooled microbolometer sensor, at up to 8.3 fps.

Does the AXIS P1290-E work in outdoor and harsh environments?+

The AXIS P1290-E operates in temperatures of -30 to 55 °C with a rating of IP66, IP67. Designed for outdoor use, it withstands severe weather conditions.

What is the zoom range and field of view of the AXIS P1290-E?+

The AXIS P1290-E has a lens with a focal length of 4 mm and a horizontal field of view of 35.4 °. This field of view covers areas such as corridors, entrances, and medium-sized spaces.

How is the AXIS P1290-E powered and installed?+

The AXIS P1290-E is powered via Power over Ethernet (PoE class 2). It includes a memory card slot for emergency local recording. A single network cable provides data and power, simplifying installation and reducing costs.

What are the key technical differentiators of the AXIS P1290-E?+

The main differentiators of the AXIS P1290-E include: 640x480 resolution; Capture up to 8.3 fps; Sensor Uncooled microbolometer; H.264 compression; Built-in edge video analytics. These features position it for demanding professional electronic security applications.

What are the main applications for the AXIS P1290-E?+

The AXIS P1290-E is especially suited for: Perimeter monitoring, Outdoor area surveillance, Visual access control, Transport Security, Cidades inteligentes. Contact our technical team to assess suitability for your specific scenario and receive a customized project proposal.

Is the AXIS P1290-E secure against cyber attacks?+

The AXIS P1290-E incorporates built-in cybersecurity features from Axis Communications, including Axis Edge Vault for device identity protection, signed firmware to prevent unauthorized software, and end-to-end encryption. Axis Communications follows the NIST secure development model, ensuring protection against cyber threats from manufacturing.
