5-year
Model: AXIS D2123-VE
Understand codeDetection radar for perimeter security
• AXIS Radar Autotracking for PTZ (Slew to Cue) for supported cameras, see axis.com/products/axis-radar-autotracking support for AXIS Camera Application Platform allowing installation of third-party applications, see axis.com/acap
• Approvals Product markings CE, CRA, CRC, ENACOM, FCC, ICASA, MIC Telecom, MOC, MTC, RATEL, RCM, RSM, SUBTEL, UL, URSE, VCCI, WPC Supply chain TAA compliant EMC EN 55035, EN 55032 class B, EN 50121-4, EN 61000-6-1, EN 61000-6-2 USA: FCC Part 15 subpart B class B railway: IEC 62236-4
• Safety CAN/CSA C22.2 No. 62368-1 ed. 3, IEC/EN 62368-1 ed. 3, EN 62311
• Network: Shielded RJ45 10BASE-T/100BASE-TX/1000BASE-T PoE
• Network: Shielded RJ45 1000BASE-T PoE out to
• Power an Outdoor PoE device Dynamic LED Dynamic LED strip with RGB (red, green, blue) LEDs and predefined light patterns Daylight visibility up to 60 m (197 ft)8
• Box-shaped detection and recognition zones our innovative box-shaped surveillance zones enable efficient and optimal coverage planning, simplifying
• System design and These zones ensure precise and reliable detection and classification of objects within a defined area, enhancing surveillance capabilities and By using unique box-shaped zones, the radar can accurately track and monitor objects in a predicted area, providing comprehensive situational awareness and the possibility for gap-free coverage and this approach optimizes coverage, ensuring effective and reliable surveillance and radar-video fusion technology our advanced radar-video fusion technology integrates data from radar devices
• Video cameras to deliver superior surveillance and monitoring performance and Initially, the radar triggers a detection and classifies it using AI, ensuring reliable monitoring over extended ranges and in challenging environmental conditions 24/7, including darkness and adverse weather and Following this, a second layer of AI-powered
• Or FIPS 140 certified hardware-based cryptographic computing module and Furthermore, signed
• Video ensures that
• Video evidence can be verified as untampered and each camera uses its unique
Axis standard warranty: 5 years against manufacturing defects.
The AXIS D2123-VE is a security radar from Axis Communications. The AXIS D2123-VE is a professional security radar that provides 270° detection coverage with AI-powered classification for humans and vehicles, ideal for wide-area perimeter monitoring in outdoor environments. It features built-in edge analytics for real-time motion detection, integrates with leading VMS platforms via ONVIF, and supports radar-video fusion with select PTZ cameras for enhanced accuracy. Available in the United States through Aeon Security, an authorized Axis partner.
The AXIS D2123-VE is a security radar that detects motion in any weather condition — rain, snow, fog — without false alarms from shadows or vegetation. It automatically classifies detected objects, distinguishing people from vehicles to reduce false alarms by up to 95%.
The main differentiators of the AXIS D2123-VE include: Built-in edge video analytics; 5-year manufacturer warranty; Aeon Security technical support. These features position it for demanding professional electronic security applications.
The AXIS D2123-VE is especially suited for: Object detection, Target Classification, High Risk Areas, Transport Security. Contact our technical team to assess suitability for your specific scenario and receive a customized project proposal.
Yes, the AXIS D2123-VE features built-in AI capabilities for edge-based analytics. All AI processing is done on-device (edge computing), without the need for an external server, ensuring lower latency and greater data privacy.
Yes, the AXIS D2123-VE is compatible with major VMS systems on the market through ONVIF and VAPIX protocols, ensuring integration with over 2,000 video management platforms.
The AXIS D2123-VE comes with a 5-year Axis Communications warranty against manufacturing defects — one of the most comprehensive in the electronic security industry. Aeon Security offers specialized technical support during and after the warranty period. Contact us at [email protected].
The AXIS D2123-VE is available on a special order basis with estimated lead times. Contact our sales team for current availability and pricing.
Expand the capabilities of the AXIS D2123-VE Radar with professional Axis accessories
Our technical team can help select the ideal accessories for your project
